SKF Sensor mounts, aluminum

SKF Sensor mounts, aluminum

Product description

Sensor mounts SKF of die-cast aluminum have a sensor bore machined by cutting methods.

The sensor bore is centered and parallel to the flange face. It can be used for attaching a sensor with male thread.

The flange with two bores serves as an interface or for fastening the sensor mount to the place of use.

RoHS-compliant product

On request

  • Stainless steel version
  • Surface ball-burnished, anodized or powder-coated in other RAL colors
  • Sensor bore with special diameter
 SKF Sensor mounts, aluminum Surface: 2 - Black, textured powder-coated, RAL 9005
Article options / Table
Show columns
for sensor
Swivel width
d2d3Length lm1m2t1t2x1x2y
B 1225305,536,5242511,57503835
B 1825305,536,5242511,57503835
Build & Price
Bore d1
Swivel width b
Part number
