SSF Sensor mounts, aluminum

SSF Sensor mounts, aluminum

Product description

Sensor mounts SSF of die-cast aluminum have a sensor bore machined by cutting methods.

The sensor bore is centered and parallel to the flange face. It can be used for attaching a sensor with male thread.

The flange with four bores serves as an interface or for fastening the sensor mount to the place of use.

RoHS-compliant product

On request

  • Surface ball-burnished, anodized or powder-coated in other RAL colors
  • Sensor bore with special diameter
 SSF Sensor mounts, aluminum
Article options / Table
Show columns
Sensor bore
Lug width
d2d3Length lm1m2t1t2x1x2y1y2
B 1840506,552,532,53010760426042
B 3040506,552,532,53010760426042
Build & Price
Bore d1
Swivel width b
Part number
If there is no weight available, please contact our customer support:
phone: +49 (0)2226 - 90 98 7 - 0
This article is RoHS-compliant in application of Annex III., which means it complies with EU Directive 2011/65/EU, including extension (2015/863/EU), for restricting the use of certain hazardous substances in electrical and electronic devices. The Directive regulates the use of hazardous substances in devices and components. The implementation in national law is summarily described with RoHS(Restriction of (the use of certain) hazardous substances)).
